Wire straightening and cutting machine
original price: 8 000 USD
Alan Xu
Contact person
Basic Information
Features: -This machine is mainly used for straightening and cutting to set length for the coil material such as cold drawn metal material, non-ferrous metal material, steel material of high speed tools and stainless steel etc. This machine is also applicable for straightening and cutting for reinforcing steel bar in prefabricated-part factory and construction site. Specification: Model DescriptionWSC-8WSC-12WSC-14Straightening diameter 4-8(σb≤450mPa)6-12(σb≤450mPa)8-16(σb≤450mPa)Cutting length 6000mm3000-6000mm4000-9000mmCutting tolerance ±1mm±2mm/m±3mmStraightening speed 25m/min30m/min20m/minStraightening motor 4KW-411KW-422KW-4Cutting motor 1.1KW-41.5KW-41.1KW-4Worm wheel reducer ---WD105-2WPA135-1Overall dimensions(without material holder)1800X900X13501800X900X13503200X950X1350
Delivery terms and packaging
Packaging Detail: wooden case Delivery Detail: 2months
Port: Shanghai
