Surface grinder GS50150AHD
original price: 30 000 USD
Alan Xu
Contact person
Basic Information
| Type | Other |
|---|---|
| Place of Origin | Jiangsu China (Mainland) |
| Brand Name | JOC |
| Model Number | GS50150AHD |
Specification: Working surface of table (mm)500X1500Max. table travel (mm)1600Max. cross travel (mm)570Distance between table surface and spindle center (mm)590Max. table load (kg)700T Slot (Number x Width) (mm)3X16Table speed (m/min)5-25Crossfeed handwheel (mm) 1 scale0.021 rev5Automatic crossfeed (mm)0.5-12Power cross feed (mm) 50Hz125060Hz1500Grinding wheel (mm) 355x40x127Spindle speed (rpm) 50Hz145060Hz1740Vertical handwheel (mm) 1 scale0.0021 rev0.5Automatic down feed rate (mm)0.005-0.04Power head increment (mm)230Spindle motor (kw)5.5Vertical motor (kw)370Hydraulic motor (kw)2.2Dust collection motor (kw)550Coolant motor (kw)90Crossfeed motor (kw)370Floor space (mm)58100x2445Packing dimensions (mm)4000x2260x2250Net weight (kg)6000Gross weight (kg)7000 Standard accessories: Grinding wheel; Wheel flange; Wheel balancing base; Wheel balancing arbor; Extractor; -Diamond dresser; Leveling pad; Anchor bolt; Tool box with tools Optional accessories: Permanent magnetic chuck; Tiltable permanent chuck; Electro-magnetic chuck; Demagnetizer; Overhead parallel dresser; Angle dresser; Radius dresser; Chuck control; Rapid elevation; Micro feed; Digital readout system; Rear splash guard; Suction device; Cooling & suction device; Magnetic separator; Cooling c/w magnetic paper filter.
Delivery terms and packaging
Packaging Detail: wooden case Delivery Detail: 2months
Port: Nantong
