Pipe bending machine

Specification: Max.Round Pipe(mm)63.5x3.0Max.Stainless Steel Pipe(mm)63.5x1.8Max.Square Pipe(mm)50x3.0Max.Round Bar(mm)28Bending Radius(mm)38-270Bending Angle(degree)0-190Mandrel working distance(mm)2800Max.bending(deg/sec)60Bending Accuracy(degree)±0.15Hydraulic Motor(kw)7.5Max.working Pressure(kg/cm²)175Hydraulic Tank Capacity(liter)170Total Width(mm)950Total Height(mm)1250Total Length(mm)3500Total Weight(kg)1400 Features: -All programs can be operated through dialogue mode touching control screen. -All information is displayed by English and Chinese with simple operation. -Can sets many different angles to bending by turns. -Possess automatic error detection function and limit protecting function. -Guiding module has auxiliary pushing function and at the same time it possesses reiterationand entering repeat functions that can make the guiding module length shorten. -Counter function can accurately count workpieces quantity. -Adoption of oil pressure valve accumulative body loop can control actions individually to prolong the lifespan of oil pressure parts. -Tri-step loop possesses cooling and deposit functions which can avoid the deteriorate oil. -Optional function of core entering and lubricating automatically. -Optional function of core reversing slowly. -Optional function of slow bending.
