Milling machine MH32B

Specification: Spindle taperISO50Distance from spindle axis to table surface (mm)0-400Distance between spindle axis and beam surface (mm)175Spindle speed range (r.p.m)58-1800Table size (mm)1320x320Table travel (mm)800(750)x300Overall dimensions (mm)1900x1720x1750Motor (kW)4N.W/G.W (kg)2100/2300 Features: -Rectangular table guide way with high stability -Table feed in X, Y axis through gear drive, motorized lifting and lowering of table on Z axis -Hardened and ground table surface -Vertical milling head attachments supplied at extra cost Standard accessories: Mill chuck; 7:24 middle-sleeve; Wrench; Inner-hexagonal spanner; Vice; Horizontal milling arbor; Horizontal draw bar; Vertical draw bar; Hexagon nut; Flat washer;
