CNC Single column vertical lathe LVS160S CNC

Specification: Max.machining diameter (mm) 1600Max.turning diameter of side tool head (mm)-Diameter of table (mm)1400Max.height of workpiece (mm)1250Max.weight of workpiece (kg)5000Horizontal travel of tool head (mm)1100Vertical travel of tool head (mm)850Speed range of table (r/min)5-160Speed steps of table (steps)SteplessFeed range of tool head (mm/min)0.1-1000Rapid traverse of tool head (mm/min)3000Total cutting force (N)25000Max. torque of table (N.m)16000Max. cutting force of tool head (N)25000Travel of cross rail (mm)1000Rise/down speed of crossrail (mm/min)660Rise/down motor of crossrail (kW)2.2Torque of servo motor (N.m)14CNC systemSIEMENS802DPower of main motor (kW)45Section size of tool bar(WxH) (mm)40x40Tool post styleSix-station electricWeight of machine tool (kg)14200Overall dimensions (LxWxH)(mm)245x3190x4750 Features: -Electrical turret for tool post -2 grades stepless for speed adjusting of spindle -This machine not only has common turning function but also can cut with constant linear velocity and threading Optional accessories: Threading device; Taper turning device; grinding device; digital display device; coolant system; CNC vertical lathe can be equipped with a function of turning in steady velocity.
